BITPSU 1000W Power Supply Review

The power supply tested today is from the professional mining power supply of Yi Neng Zhe. This new brand has been designed in the style of a supercar since its launch, so the power supply packaging, shell, and internal heat sink are all decorated. Considering the miners, the AC switch was simply adjusted. In order to make it more convenient for miners, a power supply tailored for miners.

Power supply model: BITPSU-1000W

Brand: BITPSU-Superpower (Professional Mining Power Supply)

Rated power: 1000W

Conversion rate: about 90% (gold standard)

Power supply appearance

Appearance components:

1: The main body of the power supply.

2: A power supply fan.

3: 3 6-pin cables.

4: PC power switch.

5: Length: 16cm Width: 15cm Height: 8.5cm

6: Net weight about 1.7KG (3.4 catties)

BITPSU-Power Supply is specially made for miners by the manufacturer, and its overall appearance is elegant and classy. As a high-end power supply product for mining, it gives people the first impression of being reliable. The large fan, conspicuous logo, punching mesh workmanship, and 3-month warranty seem to have made people feel at ease.

The 1000W professional mining power supply feels very heavy in the hand. The power supply shell is made of 0.6mm thick nickel-plated alloy material, which not only feels very smooth, but also greatly reduces the radiation hazard to the human body when the power supply is working.

Power brand

This Platinum Power Supply has a rated power of 1000W, 12V output, and a current limit of 83A MAX. The maximum output power can reach 996W, accounting for about 99.6% of the total power, and the output capacity is very good. There is a website in the lower left corner of the power supply parameters.

Power tail

The tail air outlet adopts honeycomb heat dissipation holes, and the structure inside the tail can be clearly seen, which can achieve good ventilation effect for the power supply.

Power cable

The power supply is equipped with a 220V input power cord. In order to reduce the operating loss of the mining machine, all pure copper national standard 3X1.0mm² wires are used, with a wire length of about 1.8 meters; the maximum withstand voltage is 300/500V, and the national standard 10A plug is suitable for all domestic mining farms.

Power supply side

The side of the power supply can be ignored. The Insect Power Supply has its own fan, one in and one out, which can fully achieve the heat dissipation effect of the power supply. The heat dissipation is very good, so there is no need to consider the ventilation problem. The following is an introduction.

Power supply fan

Heat dissipation: The power supply uses a 12cm large windmill fan for heat dissipation, the fan driving current is 0.27A, the noise is very small, the fan is made of good materials, and the fan blades are thick.

The front is equipped with a round detachable metal grille, which can be removed by unscrewing 4 screws, making it easy to clean after long-term use. And there is no decoration, which are the characteristics of entry-level power supplies.

Power cable

Wire: The wire is not wrapped with nylon mesh. I believe all miners like this, it is convenient to organize the wires. The temperature of the wires can also achieve good heat dissipation.

The 1000W power supply is equipped with three 6-pin cables, 50cm and 20cm in length, all of which are high-specification 18-gauge electronic cables, which increase transmission efficiency and reduce losses. It is also equipped with an AC main switch, which is specially designed for mining, eliminating the trouble of having to equip the PC power supply with a switch and short cables, effectively solving unnecessary troubles for miners.

Internal structure of power supply

Internal circuit, component diagram, black solder mask PCB highlight the high-end product style of the special ability. All Japanese capacitors, VAC high-quality amorphous magnetic rings are luxurious materials, and the insulation treatment that can be seen everywhere is very detail-oriented. The EMI filter components on the main PCB, complete two-stage EMI filtering, fuses and MOV varistors are used to protect against surge voltage.

Power capacitor

The main capacitor is from Hitachi, the quality is very good, the capacitance value is 560uF, the withstand voltage is 450V, the temperature resistance is 85 degrees Celsius, and the specifications are also very good.

To summarize: Remember: This power supply can only work between 90V and 264V. When tested at 57% load, the power conversion rate can reach over 90%. It is a gold medal power supply.

There are many types of Bitcoin mining power supplies, and the conversion rates are also different. If you need to use a Bitcoin mining power supply, the one in this article has a high conversion rate and is relatively cheap. For large-scale deployment, it can save considerable power cost investment. However, if you encounter some Bitcoin mining power supplies with low conversion rates, you must consider the electricity cost, safety and stability.

However, it should be noted that different ambient temperatures, different mining machine temperatures, and different mining machine fan speeds will all affect the total power consumption, so the above figures are for reference only.
