Delta 1600W Power Supply Review

Power supply model: DPS-1600BB

Brand: Delta

Rated power: 1600W

Conversion rate: about 90% (Platinum)

Power supply appearance

Appearance components:

1: The main body of the power supply.

2: Two power supply fans.

3: 4 6-pin cables.

The overall appearance of Delta's 1600W power supply adopts a silver-gray matte treatment, and uses honeycomb-shaped heat dissipation holes on both sides of the power supply, highlighting the high efficiency of Delta DPS-1600BB.

Power nameplate

This Delta platinum power supply has a rated power of 1600W, 12.2V output, and a current limit of 147.5A MAX. The maximum output power can reach 1799.5W, accounting for about 89% of the total power, and the output capacity is very good.

Power tail

Power cord

The power supply is equipped with a 220V input power cord. In order to reduce the operating loss of the mining machine, all pure copper national standard 3X1.5mm² wires are used, with a wire length of about 1.8 meters; the maximum withstand voltage is 300/500V, and the national standard 16A plug is suitable for all domestic mining farms.

Power supply side

The air outlets on the left and right sides of the power supply use honeycomb-shaped heat dissipation holes, and you can see the huge yellow boost inductor through the heat dissipation holes.

The foreskin and the internal structure on both sides can give you a slight sense of its strength, which helps to achieve better heat dissipation.

Power supply fan

Cooling fan: The power supply uses a double ball bearing cooling fan, the fan drive current is 0.55A, and the sound is within the normal range of 0.60A. The fan is made of good materials and the fan blades are thick.

It can be clearly seen that the 1600W Delta power supply uses dual fans to achieve better ventilation.

Power cable

Cable: Delta DPS-1600BB power supply is equipped with 4 6-pin cables, 50cm long plus 20cm long.

They are all high-specification 18-gauge electronic wires, which increase transmission efficiency and reduce losses.

To summarize: Remember: This power supply can only work between 200V and 240V. When tested at 41% load, the power conversion rate can reach over 90%. It is a platinum power supply.

There are many types of Bitcoin mining power supplies, and the conversion rates are also different. If you need to use a Bitcoin mining power supply, the one in this article has a high conversion rate and is relatively cheap. For large-scale deployment, it can save considerable power cost investment. However, if you encounter some Bitcoin mining power supplies with low conversion rates, you must consider the electricity cost, safety and stability.

However, it should be noted that different ambient temperatures, different mining machine temperatures, and different mining machine fan speeds will all affect the total power consumption, so the above figures are for reference only.
