How to mine Dash in f2pool using Antminer D3

1. Preparation

1 Hardware preparation: a Dash mining machine D3, a power supply equipped with the mining machine, an Internet cable, and a computer.

2 Download the IP search software: https://pan.baidu.com/s/1o8UiM3C.

3 Prepare a Dash wallet address. You can get it from a trading platform (such as P network: https://poloniex.com/), or you can download a local wallet from the official website.

2. Mining machine assembly

1 First connect the network cable and insert it into the network cable interface of the mining machine.

2 Then connect the power cord and connect the various interfaces of the mining machine power supply to the mining machine. The power supply has 10 wires, which are connected to the control board and the computing board respectively. After connecting all the wires, you can turn on the power supply. At this time, the light of the mining machine starts to light up and the machine starts to run.

3. Find the mining machine IP

Unzip the downloaded IP Finder and double-click IPReporter in the folder.

Click "Start", then press and hold the IP Reporter button of the mining machine for one second and then release it.

At this time, the IP address of the mining machine will automatically pop up on the software. Copy the IP address to the browser.

Open the browser, paste the mining machine IP found above into the browser address bar, press Enter, in the pop-up authentication, enter "root" for both the username and password, and click OK.

4. Set up the mining machine background

At this time, we will enter the background of the mining machine management, and set up three mining pools in Miner Configuration/General Settings.

URL: Fill in the F2Pool mining address dash.f2pool.com:5588 (see the figure below).

Worker: Create a miner name in the format of wallet address.numbers or lowercase letters. One miner name for each mining machine.

Password: miner password (can be set at will).

After setting up the three mining pools, click “Save&Apply” in the lower right corner.

5. Check the running status of the mining machine

At this time, enter Miner Status and refresh it several times to see the current operation status of the Antminer. Here you can see the running time, computing power and other data of the miner at the default frequency, which is convenient for miners to monitor the operation of the miner.

You can also set the mining frequency in the advanced settings:

6. F2Pool official website monitors computing power and revenue

Open the official website of F2Pool https://www.f2pool.com/, copy the Dash wallet address to the address bar in the upper right corner, and click View

Or directly open the URL https://www.f2pool.com/dash/<wallet address> and enter the computing power and income monitoring page:

In addition, please log in to the help page to view the relevant instructions of the Dash mining pool https://www.f2pool.com/help. The minimum payment for Dash is 0.1 DASH.

Ant D3 Dash Miner: http://www.wabi.com/product/7.html
