SFARDS SF100 mining machine first batch released, priced at 8,000 yuan

Product Features

• Built-in 24 SF3301 Bitcoin & Litecoin dual mining chips

• Higher computing power, lower power consumption, and longer life cycle

• Double or single digging is optional, more flexible configuration

• Overclocking and downclocking are possible, with more application scenarios

• Suitable for mining Bitcoin, Litecoin, and most cryptocurrencies on the market

• Pluggable hash board design, easy to maintain and disassemble

• High current DCDC module separate design, DCDC module can be reused for multiple generations of chips in the future




• Hashrate:

parameter	SHA-256 (Bitcoin, etc.)	Scrypt (Litecoin, Dogecoin, etc.)
Hashrate	1700GHS ± 5%	54MHS ± 5%
Dual mining power consumption	970 W (at the wall)
Single mining power consumption	710 W (at the wall)	200 W (on the wall)
Power efficiency	0.42 W/GHS	3.7 W/MHS

• Chip: 24 SF3301 (SFARDS independently developed, the world's first FD-SOI 28nm dual-algorithm chip)

• Hash boards: 3, each with 8 SF3301 chips

• Dimensions: 430 x 191 x 178 (unit: mm)

• Product weight: 5.8KG

• Cooling method: air cooling, 3 groups x 8 heat sinks, single fan

• Network connection: Ethernet port

• Control method: Raspberry Pi with built-in BitStellar software (formerly WiiBox), network control

• Power input: 12V DC, 6 6-Pin PCIE cables.

• Note: SF100 does not include a power supply. The actual operating power consumption is related to the performance of your power supply.




• SF100 mining machine open source information: https://github.com/sfards

BTC hashrate operation chart

LTC hashrate operation chart
