Innosilicon A9 Mining Machine Tutorial! Zcash Mining Machine

Algorithm: Equihash

Hashrate: 50Ksol/s (+-8%)

Power consumption: 620W +/- 8%

Dimensions: (L)360mm*(W)125mm*(H)155mm

Weight: 5.13KG (without power supply)

PSU: Output power greater than 1000W, 7 * PCI-E 6Pin

Working temperature: 0-85℃

Network type: Ethernet

1. Before assembling the miner, pick up the miner and shake it slightly. If there is a sound of metal collision, please contact after-sales service immediately.

2. Check whether the warranty sticker of the mining machine is damaged (the warranty sticker at one end of the power interface of the hash board shall prevail). If there is any damage, please contact after-sales service in time.

3. Check that the two fans of the mining machine are working properly. If the fans are damaged or cannot work properly, please contact after-sales service in time.

1. Power cord connection

Each hash board needs to be plugged into two power cords, and the control board needs to be plugged into one power cord, as shown in the following figure:

2. Network cable connection

Plug both ends of the network cable into the router and the control panel network cable interface as shown in the figure below.

1. Check the machine version information

Go to the Overview page to view it, as shown in the figure.

2. Upgrade the firmware

Go to the Maintenance page and select the Firmware interface to upgrade the firmware.

3. Password change

Enter the Settings interface and select the Security interface to change the password.

4. Restart the machine

Go to the Maintenance page and select Reboot to restart the machine.

5. Restore factory settings

Enter the Maintenance page and select Factory Reset to restore the mining pool settings and login password of the machine to factory settings.

Is it necessary to restart the machine and restore factory settings in the background?

You can also use the IPset and Reset buttons on the machine.
