Antminer interface description

1. Home page: Here you can see the model, firmware version (file system version), running time, memory status, network connection, etc.

2. Administration: Here you can modify the login password of the mining machine. It is recommended not to modify it. If you forget the password, you can only restore the mining machine to factory settings.

3. Upgrade page: Here you can upgrade the firmware, back up configuration information, restore configuration information, and restore factory settings.

4. Restart the mining machine. You can soft restart the mining machine on this page.

5. Here you can modify the mining pool and miners of the mining machine

6. Network settings

7. Operation status

A: Running time B: Mining machine computing power C: Mining pool status, Alive is connected D: Error rate, normally no more than 0.03%

E: Serial number of computing board F: Number of chips G: Operating frequency H: Computing power of a single computing board

I: Computing board temperature J: Chip temperature K: Chip status (X or - indicates a problem)

L: Speed ​​of two fans

HW: Hardware error count. You don't need to pay attention to this. Just look at the D error rate. Just look at the error ratio, not the specific data.
