CoinWise Review: Antminer L3++ Review

Recently, Bitmain's official website launched the upgraded version of Antminer L3++ and L3+. The parameters written on the official website are exactly the same as those of L3+, only the price is more expensive. RU kidding me?

The official website product description uses red fonts to indicate that L3++ may have better parameters than L3+.

What is Bitmain keeping in suspense?

We got an L3++ from the official Antminer to do a review for everyone and find out more.

Ding ding ding, the pig's feet are on stage, unboxing photos

Same packaging, same instructions

The same styling label name is L3++

Front view of ANTMINER L3++

There is no difference...

Take a closer look at the label, Submodel: 580M, those who are familiar with Antminer know what this means. 580M hashrate, 504M L3+, surprise!! This is what the official website calls the better parameter 580M

Actually, I saw 580M when I got the box, haha

Next, let’s do a more detailed parameter evaluation!

Test tool preparation

Official electricity, power meter, temperature gun, noise meter

Connection assembly

Connect the power supply, plug the power meter into the socket, connect the network cable to the router, and you are ready.

Turn on the switch to start testing

Green light on, working normally

Log in to the mining machine console with a computer, find the IP address of the mining machine (search through the router, or use the mining machine IP search tool), and enter http://mining machine ip in the browser (for example: http://192.168.1.123)

Successfully enter the mining machine login interface, enter the default password root root to enter the mining machine console

From the console we can see the mining machine model Antminer L3++

Switch to the Miner Configuration tab to configure miner information

We use the official ant mining pool antpool

After the configuration is saved, the mining machine will automatically restart to apply the new configuration

Let's switch to the Miner Status tab to view the miner's operating status.

After the mining machine runs stably, we will measure the power, temperature and noise parameters of the mining machine.

Power: 1049.9W

The noise level of the mining machine at close range is 82.5 decibels

The noise level of the mining machine at 5 meters away is 70.4 decibels

The air outlet temperature is 39.7 degrees. Since it has just been running for a while, the temperature is not high. We will test it again after running for a while.

After the mining machine is working stably, we let it run for 12 hours to see how stable it is.

Okay, 12 hours have passed.

Let's test the temperature again.

The temperature at the air outlet is 46.7 degrees, which is not high.

Check the mining machine status

The average hashrate is 586M, the hashrate board temperature is below 50 degrees, and the working condition is good.

Go to AntPool to check the computing power

The computing power is 596MH/s, which is relatively stable and even exceeds the official parameter of 580M.

Summarize:

Test results and comparison data

Although the computing power of L3++ is 76M higher than that of L3+, we can also see from the test that the power consumption is also much higher, and the power consumption per unit computing power is higher than that of L3+.
