Jasmine X4-1U Blade Computing Server Review

Eth has long been dominated by graphics card miners. I believe everyone must remember the situation in the middle of the year when it was hard to get a card. Although graphics cards are now in sufficient supply, aren’t chip machines more attractive? Today, the editor will review this high-throughput chip computing server Jasmine X4-1U for everyone. Let’s take a look at how attractive it is.

First, let’s take a look at the unboxing photo: host, power cord, instruction manual, and certificate of conformity.

To be honest, I was amazed the moment I opened the box. It was the first time I had seen such a thin and light machine. Now let's take a closer look to show you what it means to be beautiful but not powerful.

Let’s stop talking nonsense and take a look at the official parameters of Jasmine X4-1U.

- Dimensions (mm): 482.2 x 450 x44.5

Power consumption: 240W ± 10%

Hashrate: 520M ± 10%

First, we measured the size of the machine. Our actual measured data is 45cm x 43cm x 4.5cm, which is actually a little smaller than the official marking.

Next we plug in the network cable, power on, and start running. After power on, the indicator light turns on.

After the mining machine is turned on, we start to connect the mining machine for configuration. Scan the two-digit code on the manual to get the video tutorial on how to configure the mining machine. Isn't it very considerate? First find the mining machine IP (those who don't know how to find the mining machine IP can follow the video tutorial in the manual), then enter the mining machine IP in the browser to connect to the mining machine. The password and username are both root. Enter the mining machine configuration interface. The interface design is very simple and generous. The only drawback may be that there is no Chinese option. However, since the operation is not complicated, you can get it done as long as you have a basic knowledge of English.

We just need to click on the miner item in the menu bar and start configuring the mining pool information.

At the bottom of the configuration, there are two official built-in frequencies and two currencies. We will take ETH as an example in this evaluation. Click the UPDATE button to update the configuration.

After the mining machine is updated, the editor strongly recommends that you download the latest firmware from the official website. The download address is here: https://www.jasminer.com/firmware. After downloading the firmware, we only need to click the menu Upgrade, then select the downloaded firmware to upload, wait for the firmware upgrade to complete, and restart the mining machine. The editor has tested that after updating the firmware, the initialization time of the mining machine will be greatly shortened (ps: eth non-graphics card machines all need an initialization), so everyone must remember to update.

The mining pool will not be displayed online during the initialization period. Just wait patiently. After the mining machine is initialized, the Normal indicator light will be flashing.

Let’s first look at the evaluation data at standard frequency.

24-hour computing power curve

24-hour average computing power 502M

Air inlet temperature 28.3 degrees Celsius

Air outlet temperature 36.3 degrees Celsius

Noise: 69.4 decibels

Power 254w

Here is another set of evaluation data for high-frequency work, which still shows a stable 24-hour computing power curve.

24-hour average computing power 579M

Air inlet temperature 26.9 degrees Celsius

Air outlet temperature 39.7 degrees Celsius

Noise: 83.5 decibels

power

Here are two more disassembly photos to experience the exquisite workmanship. It is definitely a blessing for people with obsessive-compulsive disorder.

Data comparison

Summarize

Although the power consumption in high-frequency mode is slightly higher than the official parameters, I believe that the excellent computing performance is enough to conquer you. The only shortcoming is that the noise performance is average, and it cannot be considered a silent model. Of course, the high room temperature may have a slight impact on the noise and power consumption. In terms of comprehensive performance, the product strength of Jasmine X4-1U is still very strong, enough to be called an excellent product.
