Beautiful lady teaches you how to upgrade S17 and T17 heat sinks

Good morning, afternoon and evening, everyone. I'm Cathy. Are you a user of the Antminer 17 series? Have you ever been troubled by heat sink problems? Has your heat sink fallen off? Has the heat sink ever short-circuited?

I have the heat sink of T17 in my hand, let's see why it has these problems.

First, we can see that this is the heat sink, and this is the chip. The soldering material in the middle is low-melting-point tin, which has a relatively low melting point of 138°C. In actual operation, it is already in a semi-melted state at around 90°C. When the machine is running, the machine overheats or the power is suddenly cut off, and the heat inside the machine cannot be discharged, causing partial melting of the soldering point. In addition, due to the gravity of the heat sink, the heat sink is easy to loosen and fall off.

In addition, since tin has low ductility and is brittle, it often falls off during transportation. And the chips are connected in series, so if one is damaged, all of them will be disabled.

This is why so many 17 series need to upgrade the heat sink, so how to do the upgrade process? Let me show you.

Preparation of materials and tools

Modification materials: heat sink, nuts, screws, upper insulation pad, lower insulation pad, and two sets of steel mesh.

Modification tools: air gun, tweezers, grinding tools, silicone grease (above 5W/m·K), and board cleaning water.

Transformation process

1. Use an air gun to remove the heat sink.

2. Grind the mold to cover the hash board, sand and level the chip, and then clean the board surface.

3. Cover the nut positioning mold and weld the nut.

4. Grind the mold cover and apply silicone grease.

5. Install the modified heat sink and secure it by driving the screws in with an electric screwdriver.

It's very simple. If you have the tools and are careful, you can do it yourself. If I can do it, so can you. We will also have instructions to help you every step of the way.

Improved effect

Now that the modification is done, what is the effect? ​​After modifying the heat dissipation mold, not only does it maintain the same heat dissipation effect as the original new machine, but the damage rate can be reduced by 90%.

Advantages and features

There are many shops and companies on the market that offer radiator modification, and some people even do it themselves. What is the difference between our radiators?

1. Excellent quality, official authorized technical support, official first-hand accessories and corresponding molds, no impact on computing power and power consumption.

2. Official cooperation design, the whole piece is fixed with screws, which is very stable and will not fall off; the front end is designed with slope, the overall gap density is larger, the air intake is larger, the rear end is horizontal, the heat dissipation area is large, the ordinary tooth density, the heat dissipation area is large, and the heat dissipation efficiency is 20% higher than the market modification; the special oxidation process is non-conductive, no short circuit, safe and stable; customized screws, can be installed directly, simple disassembly and assembly; groove design, the heat sink is arranged between the rows of chips, and will not shift, and will not cause any pressure on the chip.

3. After-sales service is more guaranteed, the goods are tested before shipment and have a 7-day warranty upon receipt.

Strength test

Cargo bump test (take a picture of a car going on a very bumpy road, then starting it and running)

Power off test (turn the machine on and off several times to see if it can be used normally)

Usage test (after running for a few hours, unpack and check the heat sink to see if it melts as before)

This is our upgrade and transformation plan using the T17 heat sink as an example. If you need it, please contact me! During the Miami Bitcoin 2022 event, we also have a promotion where you can buy an upgraded heat sink for $99. Contact me now!
